Electronics-II

Welcome to the Lecture of Electronics-II

Lecture#01(16/09/11)

• Introduce the Course.
• Syllabus and
• Course plan

Electronics-II.doc (27,5 kB)

Lecture#02()

• P-N junction.

• DC load line

• Transistor operation

• Classification of linear amplifiers.

Lecture#03()

• Amplifier Classification Based on biasing conditions.
• graphic Representation of Class-A, Class-B,Class-AB amplifier.
• Charecteristics of Class-A Amplifier.

Lecture#04()

• Powe Distribution in a Class-A amplifier.
• Power rectangle of Calss-A amplifier.
• Power efficiency and Maximum AC power in load for Class-A amplifier.
• Example that should be practiced ex-60.5, ex-60.6
• transfoemer coupled Class-A Amplifier, power diagram and maximum efficiency calculation.
• Example that should be practiced ex-60.7, ex-60.8
• Class-B amplifier, characteristics,Power relations,Maximum efficiency calculation.

Lecture#05()

• Class-B push- Pull amplifier.
• Crossover distortion
• Powe efficiency of push- Pull amplifier
• Class-C amplifier.
• Multistage amplifier.
• Cascaded amplifiers, compound amplifiers
• Amplifier coupling.
